10” Touchscreen Quad View Monitor with 1080p Support (NSM-104QT)

10” Touchscreen Quad View Monitor with 1080p Support (NSM-104QT)

$999.95incl. GST
Product Enquiry

Description

The NSM-104QT supports AHD 1080p/720p camera to display rich and detailed video unmatched by standard definition cameras. The intuitive capacitive touchscreen controls any camera feed, touch the video feed and that camera switches to full screen, touch again to go back to multi-camera mode. Many different view modes available. With a multitude of setup options and 5 triggers, the NSM-104QT can trigger and display blind spot cameras, reverse camera etc. Camera connections are a weather sealed 4 pin type which incorporate the video/audio feed as well as power for the cameras (4 pin to RCA adapter cables available – not included – Part number F4PIN-FRCA).

Note: When using standard cameras with the NSM-104QT, the video resolution is limited by the resolution of the camera. This monitor cannot control the menu of a DVR, view only.

  • 4 Channel Quad View Monitor
  • Capacitive touchscreen
  • Supports up to 4 Full HD 1080p cameras
  • Multiple image display modes
  • Image view options: Flip, Normal, Zoom
  • 5 triggers with priority/delay options
  • Screen resolution: 1024 x 600
  • Internal 1.5W speaker
  • VGA input
  • Operating temp: -20º ~ +70º
  • Power: 10-32v with 12v output to cameras
  • Size: 267mm (W) × 160mm (H) × 30mm (D)
  • Includes: U bracket, dash mount, IR remote, power/camera harness, 2m (F) 15 Pin Dsub VGA cable (M-M cable or adapter required to connect to DVR-4200AHD), sunshield.
